The new modular connectivity solution for your board application. CREATE YOUR OWN!
Developing engineers for electronical industry devices knows this problem. The livelines of data, signal and power have to be connected from one PCB to another, and the most stock connectivity solutions do not fit for the own project. No reason to despair. The new HARTING har-modular® PCB connector system gives you over a billion combination possibilities for data, signal and power. Configurable online by yourself from quantity 1. The ideal solution for innovative prototyping or your next successful device series.
Modularity and flexibility are becoming increasingly important in equipment development. The development times of new devices are becoming shorter and shorter and prototyping is playing an increasingly important role. A limited selection of available standard components is often an obstacle in device development. The solution to this need for modularity, flexibility and more speed in device development is called har-modular. A plug connection with future potential that can be configured absolutely individually by the customer. No matter how innovative and creative the arrangement within a device design, it is no longer dependent on whether a suitable standard strip or variant is available. The developer adapts the connector to his requirements. Not vice versa. Every solution is conceivable and can be realised from batch size 1. This offers developers completely new perspectives for fast and cost-effective prototype development.
3 steps to your individual connector
STEP 1 – How many modules
In the first step you have to ask yourself what lifelines and how many lifelines you want to connect. Data, signal or power? Or all three? Check out our har-modular® modules.
STEP 2 – The guiding pin
For a safe connection of all your modules, every har-modular® connector needs two guiding pins. Depending on your application you can select them in plastic or metal. If you ask us, the best places for the guiding pins are the connectors ends, but every other place is also possible.
STEP 3 – The connecting rail
Found the right sort and number of connection modules? Two guiding modules? Perfect. Lets finish.
